Min. Myalelo:1 Piece/Pieces
I-12.1InCh i-1280 * I-800 Ukuzalwa kwe-80000 I-ITD ye-LCD, i- TFT LCD Screen, Uyilo lweNdawo yokuHlola, uLuhlu oluPhezulu, ukuSebenza okuPhakamileyo, okhethekileyo. Imodyuli ye-LCD yokubonisa kumdlali wangaphandle osetyenzisiweyo.
Imveliso yezixhobo ezongeziweyo
Isicelo semveliso:
|
Size
|
12.1inch
|
|||
|
Panel item
|
RS121NET-N10
|
|||
|
Panel type
|
a-Si TFT-LCD
|
|||
|
Display mode
|
IPS,Normally white，transmissive display
|
|||
|
Pixels
|
1280*800
|
|||
|
brightness
|
1000cd/m2
|
|||
|
Constrast Ratio
|
700：1
|
|||
|
Response Time
|
4/12ms
|
|||
|
View angle
|
80/80/80/60
|
|||
|
View area
|
263.52*165.6mm(H*V)
|
|||
|
Dispaly area
|
261.12*163.2mm(H*V)
|
|||
|
Outline Size
|
283*185.1*10.2mm(H*V*D)
|
|||
|
Signal Type
|
WLED
|
|||
|
Working freqyency
|
60Hz
|
|||
|
Working temperature
|
-30~80ﾟC
|
|||
|
Storage Temperature
|
-30~80ﾟC
|
|||
|
Display ratio
|
16:9
|
|||
|
Display color
|
16.7m
|
|||
|
Supply Voltage
|
3.3V
|
|||
|
Surface Treatment
|
Haze
|
|||
|
Weight
|
0.62kgs
|
|||
I-TAGS eshushu: I-1280x800 i-LCD eqaqambileyo ye-LCD i-12.1inch, i-China, i-InCD ye-InCD, iXesha le-InCD, i-SCIT, i-WCD ye-InCD ye-LCD, ipaneli ye-15 ye-15 i-LCD , Iphaneli ye-12 3 ye-LCD , iphaneli ye-LCD, imodyuli ye-LCD, ibonisa ukukhanya okuqaqambileyo.
I-17NCH Imodyuli eqaqambileyo ye-LCD
I-1500NITS ye-LCD yokusetyenziswa kwangaphandle
