Ibhanti: Ukunyuka
Ukunyuka kwe-12.1 i-intshi encinci ye-intshi i-screen-s.15, ukuqaqamba kwe-1500, le modyuli ye-LCD isekwe ekukhanyiseni ukukhanya kwe-backdoor esetyenzisiweyo. Umgangatho ophakathi wokubuyela umva, unokwenza isikrini kwisiseko semodyuli yoqobo kubonisa ukukhanya okuphezulu, yenza ukubonakala kwe-LCD Screen Screen.
I-12.1 I-Inch Crit LCD Screen (i-Rs11-N15) Le yiphaneli ye-LCD ye-LCD, i-1000: i-19/89/89, i-Wight Life iiyure ezingama-50k ezingama-50k iiyure ezingama-50k.
I-12.1 I-Inch LCD Screen inokuxhotyiswa ngeBhodi ye-Codd Drive, ibhodi ye-AD, iadaptha yeAc kunye neentambo. 12.1 Imodyuli ye-Inch LCD ngomgangatho ophezulu kunye nexabiso eliphantsi, wamkelekile kwi-odolo yakho.
Parimeter
| Size | 12.1inch |
| Panel item | RS12.1NET-N15 |
| Panel type | a-Si TFT-LCD |
| Display mode | IPS,Normally black，transmissive display |
| Pixels | 1280*800 |
| brightness | 1500cd/m2 |
| Constrast Ratio | 1000:1 |
| Response Time | 25ms |
| View angle | 89/89/89/89 |
| View area | 264.22*168.12mm(H*V) |
| Dispaly area | 261.12163.2mm(H*V) |
| Outline Size | 278*184*9.94mm(H*V*D) |
| Signal Type | LVDS,30 pin |
| Working freqyency | 60Hz |
| Working temperature | -30~85℃ |
| Storage Temperature | -30~85℃ |
| Display ratio | 16:10 |
| Display color | 16.7m |
| Backlight Voltage | 3.3V |
| Surface Treatment | Haze |
| Weight | 0.39kgs |
