Min. Myalelo:1 Piece/Pieces
Umzekelo No.: BA104S01-100
I-Ba104S01 (Boe) usebenzisa itekhnoloji ye-A-Sift ye-LCF. Ixhotywe ngokukhanya kwesibane, akukho kuqhuba i-back drive kwaye akukho phepha. I-BA104S01-100 ibonisa isigqibo sama-800 (RGB) × 600 (i-SVGA), umlinganiso we-4: 3 (ububanzi), kwaye iipikseli zilungelelaniswe kwimigca yemveliso ye-RGB, ngokuhambelana nenguqulo .1 ikhutshwe yi-Boe nge-12 kaDisemba ka-2014. × 5.9 (ubukhulu) mm, unyango lomphezulu lucacile, ubunzima bemveliso yemveliso yi-288g Isibane semveliso le mveliso isebenzisa umthombo wokukhanya we-6s6p I-BA104S01-100 yamkela i-LVDS (1 Ch, i-6/8-bit) isinxibelelanisi semiqondiso, iyonke iyonke, ukwahlukana ne-tionrial protage yi-3.3v (i-Consct.). Ireyithi yayo yokuphononongwa ethe nkqo i-fv yi-60hz. Isebenza nge-2 ° C ukuya kwi-70 ° C kunye ne-3 ° C ukuya kwi-80 ° C. Le modeli iyacetyiswa ukuba isetyenziswe kwi-mveliso kunye nezonyango ngenxa yexesha layo elimhlophe le-LED, ngaphezulu kwe-50 000 yeeyure zobomi, i-terminal flip, i-6/8 i-bit ye-grey grey grey engwevu, kunye nezinye izinto.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Oku kulandelayo ziimodeli ezifanayo kunye neeparamitha
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
Iithegi ezishushu: I-Boe Bai104S01S010NITS Isikrini se-LCD sokuphuma ngaphandle , ipaneli ye-LCD, imodyuli ye-LCD, ibonisa ukukhanya okuqaqambileyo.
I-Boe Ev101wxm-N81 Ukukhanya okuphezulu kwe-LCD
12.1 I-Boe Av121X0m-N10 LCD Imodyuli
