Iimpawu zeMveliso

Umzekelo No.: EV101WXM-N81

Ukupakisha kunye nokuhanjiswa

Ukuthengisa iiyunithi:

Piece/Pieces

Intshayelelo Intshayelelo

I-Ev101wxm-N81 yimodyuli ye-10.1 ye-intshi ye-intshi isebenzisa itekhnoloji ye-TFFD ye-LCF. Ixhotywe ngokukhanya kwesibane, kubandakanya umqhubi we-LED Thumela i-back drive, akukho phepha. Isisombululo sokubonisa siyi-1280 (i-RGB) × 800 (i-WXGA), i-racious (ububanzi), kwaye iipikseli zilungelelaniswe kwi-RGB yemivimbo ye-RGB. Ubungakanani bayo bendawo ye-216.96 × 135.6 (ububanzi] MM, ubukhulu becala yi-MM, ubungakanani bobubanzi) × 152.4 (Tyhule.). Ngokuphathelele kokukhanya okungasemva, le mveliso isebenzisa umthombo wokukhanya okukhanyisiweyo kunye nobomi beeyure ezingama-50k, kubandakanya umqhubi we-LOP. I-Ev101wxm-N81 isebenzisa i-LVDS (1 Ch, i-8-bit) isinxibelelanisi se-20, itotali ye-20, isebenzisa unxibelelwano lwe-tertage, i-voltage i-tertage yi-3.3v.). Ireyithi yayo yokuphononongwa ethe nkqo i-fv yi-60hz. Isebenza nge-2 ° C ukuya kwi-70 ° C kunye ne-3 ° C ukuya kwi-80 ° C. Ngokusekwe kwi-White Shighlight ukukhanya, ubomi bungaphezulu kwe-50,000 iiyure.

I-R-Star ivela eShenzhen, China, singuMvelisi oSebenzayo we-LCD ephezulu ye-LCD, kubandakanya iimodyuli ze-intshi ze-TCF, kubandakanya i-LCD ye-TCF, i-Istdool ye-TBD, i-Ultrathin ibalaselisa i-LCD, ngaphandle Amagqabantshintshi e-LCD, i-TFT ye-ITFD ye-LCFD, i-LCD ye-LCD, i-LCD ebonakalayo ye-LCD kunye nesakhelo somboniso, i-LCD ephindwe kabini, ukukhanya kwe-pie-piest windows kunye nepaneli ye-LCD ephezulu. Ngamafutshane, ukhula kuneminyaka engaphezu kwe-5 yokukhanya okuqaqambileyo kwe-MODE yeThekhi lemodyuli yemodyuli yemodyuli yemodyuli yemodyuli, yophando kunye nophuhliso, iminyaka eli-10 ye-10 yemveliso ephezulu yokubonelela ngezinto eziphezulu.

brand	BOE	Model name	EV101WXM-N81
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800, WXGA, 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96×135.6(H×V)mm	Surface treatment	/
Visual size	233.2×152.9×10.4(H×V×D) mm	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	233.2×152.9×10.4(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Imodeli efanayo yemodeli kunye neeparamitha zezi zilandelayo

brand	BOE	Model name	EV101WUM-N20
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1200, WUXGA, 224PPI	Pixel configuration	RGB vertical bar
Display Area	216.806×135.504mm(H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	229.45×149.22(H×V)mm
Viewing Angle	80/80/80/80(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 45 pins
work environment	Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	AT101WSM-N11-58P0
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×600, WSVGA, 117PPI	Pixel configuration	RGB vertical bar
Display Area	222.72×125.28mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	226×128.6(H×V)mm	Contrast Ratio	500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	235×144.9×5.44mm(H×V×D)
Viewing Angle	80/80/60/70(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) , 60 pins , FPC
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	EV101WXM-N82
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800 [WXGA] 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96 × 135.6 mm (H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	228.6 ×149.2×6 mm (H×V×D)
Viewing Angle	85/85/85/85(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C
