Min. Myalelo:1 Piece/Pieces
Umzekelo No.: LQ150X1LG96
Iqondo lokusebenza le-LQ150X15G15LG 1006 ngu-0 ~ 65 ° C, kunye neqondo lobushushu lokugcina ukuba-30 ~ 70 ° C. Ilungele izicelo zemizi-mveliso, amanqaku angaphandle, imidlalo. Unyango lomphezulu yi-Matte, i-hard caides (3h), kunye nobunzima bemveliso yemveliso yi-950g (i-max.). Ngokwesibane esingasemva, umthombo wokukhanya wecala esecaleni unexesha lokuphila iiyure ezingama-30k.
Isisombululo se-LQ150X15LG16 I-Snocial Storement yi-1024 (i-RGB) × 768 (i-XGA), umyinge we-4: 3 (ububanzi), kwaye iipikseli zilungelelaniswe kwi-RGB yemivimbo ye-RGB. Ubungakanani bendawo yokubonisa ye-LQ150X15X16 ngu-304.128 × 228.096 (W) I-MM, kwaye ubungakanani bangaphandle yi-326.5 (d) mm.
| brand | Sharp | Model name | LQ150X1LG96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 1050cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1 mm(H×V×D) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) | work environment | Storage temperature: -30 to 70 °C Operation Temperature: 0 to 65 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
Iimpawu ezishushu: I-15nch Sharp LQ150X15X16 TFT LVFD I-Itcheds, i-Screen Screen, i-Screen Screen, isikrini se-LCD ye-TV, Iphaneli ye-LCD ye-LCD 2500 i-ITS , iphaneli ye-LCD, imodyuli ye-LCD, i-SHROFICH SHORT.
