I-LQ150X1LW96 I-SHAFT TFT LCD Panel LVDS Screen Screen

Min. Myalelo:1 Piece/Pieces

Iimpawu zeMveliso
Ukupakisha kunye nokuhanjiswa
Other information

Iimpawu zeMveliso

Umzekelo No.: LQ150X1LW96

Ukupakisha kunye nokuhanjiswa

Ukuthengisa iiyunithi:

Piece/Pieces

Intshayelelo Intshayelelo

I-LQ150X15lw96 Isisombululo sokubonisa siyi-1024 (i-RGB) × 768 (xga), umyinge we-4: 3 (ububanzi), kwaye iipikseli zilungisiwe kwimitya ye-RGB. Ubungakanani bendawo yokubonisa ye-LQ150X146 yi-304.128 × 228.096 (W) MM, kwaye ubungakanani bangaphandle yi-326.5 (d) mm. Ukugqitywa kweMatte, ukuthutha okukhohlakeleyo (3h), ubunzima be-950g (i-max.)

Ikupheleni ngasemva yamkela umthombo wokukhanya okukhanyayo, ubushushu bayo bokusebenza bungo-20 ~ 70 ° 70 ° 70 ° 7

brand	Sharp	Model name	LQ150X1LW96
size	15inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×768 [XGA] 85PPI	Pixel configuration	RGB vertical bar
Display Area	304.128×228.096mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	307.2×231.1mm(H×V)	Contrast Ratio	1500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	326.5×253.5×10.1(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)	work environment	Storage temperature: -25 to 70 °C Operation Temperature: -20 to 70 °C
Signal interface	LVDS (1 ch, 6/8-bit),erminal,20 pins
supply voltage	3.3V (Typ.)

Umboniso we-LCD

Q: Ngaba uyenza (umzi-mveliso)?

A: Ewe, sithi. Inkonzo ye-OEM / i-ODM iyafumaneka apha. Kuluyolo lwethu ukubonelela ngesisombululo esifanelekileyo kuwe.

Q: Ndingayithenga isampulu ye-odolo yam?

A: Ewe, nceda ukhululeke ukunxibelelana nathi.

Ukukhanya okuphezulu kwe-LCD
