Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Min. Myalelo:1 Piece/Pieces
Ibhanti: Ukunyuka
Imveliso: 160K
Indawo yokuQala: Shen Zhen
Sekiso: CE/ROSH/UL/ISO9001
| Panel Brand | RISINGSTAR | Panel Model | RS220WPM-NE10 |
| Panel Size | 22.0" | Panel Type | a-Si TFT-LCD , LCM |
| Resolution | 1680(RGB)×1050, WSXGA+, 90PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 473.76(W)×296.1(H) mm | Bezel Opening | 477.7(W)×300.1(H) mm |
| Outline Size | 493.7(W)×320.1(H) ×10.7(D) mm | Surface | Antiglare (Haze 25%), Hard coating(3H) |
| Brightness | 1000nit or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/80/80 (Typ.)(CR≥10) | Display Mode | TN, Normally White, Transmissive |
| Display Colors | 16.7M 72% NTSC | Response Time | 1.5/3.5 (Typ.)(Tr/Td) |
| Frequency | 60Hz | Lamp Type | 3 strings WLED , 40K hours , Without Driver |
| Weight | 1.83Kgs (Typ.) | Input Voltage | 5.0V (Typ.) |
| Signal Interface | LVDS (2 ch, 8-bit) , 30 pins Connector | ||
| Environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -25 ~ 60 °C | ||
I-Rs220wpm-Ne10 yi-22 intshi yokukhanya kwelanga efunwayo exhasa isinxibelelanisi se-LVDS. Ingasebenza kumaqondo obushushu avela -20 ~ 70 ℃ kunye neemvavanyo zokugcina ezisuka -30 ~ 80 ~. I-Rs220wpm-Ne10 yi-1000 i-1000 i-bit ephezulu ye-Tft ye-LCD ye-LCD yemodyuli. Ilungele izixhobo zemizi-mveliso, izixhobo eziphathwayo, izixhobo zonyango, ngaphandle kunye nendawo yokuphuma ngaphandle.
Iimbonakalo
1. Ukuqaqamba okuphezulu, umahluko okuphezulu, ixesha lokuphendula ngokukhawuleza, inkxaso yemibala emininzi, i-engile ebanzi;
2. Inombolo yemveliso kazwelonke yobungcali, izigidi zendalo engenamantla-uthuli, iZiko lezikrini kunye nescreen se-LED;
3. Isiqinisekiso, fcc, CE, CE, CCC, UL, ROHS;
4. Ubuchwephesha boBuchule boBuntu obuNcediweyo.
5. Isakhiwo esomeleleyo, ifuthe lokuchasana ne-anti-langaphandle, i-chassis yentsimbi.
1. Ingcali yangaphandle yokukhanya kwepaneli ye-LCD
2. Isikrini se-LCD esiphakamileyo se-LCD, sinokumela i-110 yobushushu obuphakamileyo
3. I-Samsung, LG, Beo, Auo, Auo, I-AUO, I-AURECUX PROUS
4. Ukubonelela ngonxibelelwano lwengcali ngaphandle kunye nesikhokelo
Q: Ndingayithenga isampulu ye-odolo yam?
A: Ewe, nceda ukhululeke ukunxibelelana nathi.
Q: Singaqinisekisa njani umgangatho?
A: Soloko uhlolo lokugqibela ngaphambi kokuba uthunyelwe;
Q: Zithini izinto eziluncedo kuzo?
A: Ixabiso eliphantsi leMveliso ephezulu, ulwazi malunga nokulandela umkhondo ngexesha elifanelekileyo.
Q: Lingakanani iwaranti?
A: Sinikezela ngewaranti yonyaka omnye ukusuka kumhla wokuhanjiswa.
Q: Ngaba uyinkampani yokuthengisa okanye umvelisi?
A: Singumzi-mveliso.
I-TAGS eshushu: I-22 i-intshi ngaphandle ye-Distrital Screen, i-China, umzi-mveliso, ixabiso eliphantsi, i-it, i-IT, i-IT Screen Press, i-Inch ye-InCD yeTV, i-InCD yeTV , I-55 intshi ye-intshi ngaphandle kwescreen
I-49 "i-1500nnit ngaphandle
I-Inch 1000nnit ngaphandle ye-LCD yomboniso
