Min. Myalelo:1 Piece/Pieces
| Panel Brand | RISINGSTAR | Panel Model | RS236ZX-NE15 |
| Panel Size | 23.6″ | Panel Type | a-Si TFT-LCD |
| Resolution | 1920(RGB)×1080, FHD 47PPI | Pixel Format | RGB Vertical Stripe |
| Display Area | 544.8(W)×320.5(H) mm | Bezel Opening | / |
| Outline Size | 577.8(W)×357.6(H)×52.2(D) mm | Surface | Antiglare (Haze 3%), Hard coating (2H) |
| Brightness | 1500 cd/m²or customized | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | Display Mode | AMVA3, Normally Black, Transmissive |
| Display Colors | 16.7M | Response Time | 6 (Typ.)(G to G) |
| Frequency | 60Hz | Input Voltage | 12V (Typ.) |
| Backlight type | WLED | Signal Interface | LVDS (2 ch, 8-bit) , 51 pins Connector |
| Environment | Operating Temp.: -30 ~ 105 °C ; Storage Temp.: -40 ~ 110 °C | ||
Ngokunyuka kweMiboniso yeDijitali, itekhnoloji yokubuyela umva ye-LED iye yaziwa ngakumbi kwiiphaneli ze-LCD. Ukukhanya okungasemva kwe-LED kunika ukukhanya okuqaqambileyo kunye namanqanaba opapashi, ukuphuculwa kokusebenza kakuhle kwamandla, kunye nexesha elide lokuphila kuthelekiswa nokukhanya kwe-fluorescent yemvelo.
Esona sibonelelo siphambili sokukhanya kwe-LED kukubonelela ngenqanaba elibanzi lemibala yemibala kunye nokhetho lobushushu bemibala. Oku kubangela ukuveliswa kombala okhethekileyo nowuqinisekileyo, ukwenza isikrini se-LCD se-LCD sikufanele ukuba izicelo ezifuna imibala ephezulu, njengeziqithi ze-movie kunye ne-studios yoyilo.
I-LED yokukhanya ukubuyela umva ikwabonelela ngokuphuculwa kwamandla empumelelo xa kuthelekiswa nokukhanya kwe-fluorescent yemvelo. Ngokusebenzisa amandla amancinci, izikrini ze-LCD ze-LCD zinokunceda ukunciphisa iindleko zamandla kwaye zinciphise i-carbon yonyawo lwenkqubo yokubonisa. Elinye ilungelo elibalulekileyo lokuphuma kwe-LED kukugcina ixesha layo elinde. Izikrini ezisekwe ngaphambili ze-LCD zinexesha lokuphila ukuya kuthi ga kwiiyure eziyi-100,000, elinde kakhulu kunelifa lemveli ye-fluorescent. Oku kubangela ukuba babe neendleko ngakumbi kwaye kunciphisa isidingo sokutshintsha rhoqo. Iipaneli ze-LCD zangasemva ze-LCD zisetyenziswa ngokubanzi kumashishini ahlukeneyo, kubandakanya ukhathalelo lwempilo, umdlalo, intengiso, umthuthi kunye nokuzonwabisa. Ziqhele ukusetyenziswa kwimiqondiso yedijithali, izixhobo zonyango, oomatshini bokudlala, kunye nokuboniswa kwemoto ngenxa yokuqaqamba okuphezulu, ukusebenza kwamandla kunye nokuveliswa kombala ochanekileyo.
Iithegi ezishushu: 23.6 I-Inch Deadlight Iphaneli ye-LCD, i-China, umzi-mveliso, i-TITS, i-Itch, i-Itch, i-WCIT, i-WCD Screen LCD, i-Wibital Screen LCD, VIDT Izikrini, i-15 4 iscd ye-LCD , iphaneli ye-LCD, imodyuli ye-LCD, i-West Show.
