I-MNF6011-1 LCD Imodyuli yesikrini

Min. Myalelo:1 Piece/Pieces

Iimpawu zeMveliso
Ukupakisha kunye nokuhanjiswa
Other information

Iimpawu zeMveliso

Umzekelo No.: MNF601EA1-1

Ukupakisha kunye nokuhanjiswa

Ukuthengisa iiyunithi:

Piece/Pieces

Intshayelelo Intshayelelo

Iqondo lokushisa le-MNF601111 yi-0 ~ 50 ° C, kunye neqondo lobushushu lokugcina u-20 ° 60 ° C. Isisombululo sokubonisa i-MNF601 yi-3840 (RGB) × 2160 (i-UHD), umyinge we-16: 9 (i-pixels), kwaye iipikseli zilungisiwe kwimitya ye-RGB. Ubungakanani bendawo yokubonisa ye-MNF6011 yi-345 × 194.4 (ububanzi × 450.72 (ububanzi) × 2,6 (ubukroti) mm.

lcd display

Ukubekwa emgangathweni kunye nokweziseko ukufezekisa iimfuno ezahlukeneyo zendalo.

Ukunyuka kwe-Star ngokubanzi Izicelo zemveliso zigubungela oomatshini bokuzimela ngokuzenzekelayo (i-ATM), indawo yokuthintela i-STARK (POS), iiKhompyuter zoomatshini (iPC), izixhobo zoncedo zorhwebo, izixhobo zokuzonwabisa, ukuzonwabisa kwefektri kunye I-Marine Shrineys Lindela. high brightness LCD

brand	CSOT	Model name	MNF601EA1-1(CSO1500)
size	15.6inch	Screen type	LTPS TFT-LCD,LCD module
resolution ratio	3840(RGB)×2160, UHD	Pixel configuration	RGB vertical bar
Display Area	345.6×194.4(H×V)mm	Surface treatment	mirror(Haze 0%)，Hard coating (3H)
Visual size	/	Contrast Ratio	1500:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	350.72×216.07×2.6(HVD)mm
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	work environment	Storage temperature: -20 to 60 °C Operation Temperature: 0 to 50 °C
Signal interface	eDP (4 Lanes),eDP1.4,HBR2 (5.4G/lane),40 pins,erminal
supply voltage	3.3V (Typ.)

Iithegi ezishushu: Mnf6011-1 LCD Screen Moudle, China, umzi-mveliso, i-Inch, ixabiso le-Inch LCD, i-SCRINGS Screen LCD, I-SCICT SCRINGS Umboneleli, isitishi sebhasi LCD Screen , ipaneli ye-LCD, imodyuli ye-LCD, i-West Show.
