I-48 "i-700NITS LTI480H01 LCD yemodyuli

Min. Myalelo:1 Piece/Pieces

Iimpawu zeMveliso
Ukupakisha kunye nokuhanjiswa
Other information

Iimpawu zeMveliso

Umzekelo No.: LTI480HN01

Ukupakisha kunye nokuhanjiswa

Ukuthengisa iiyunithi:

Piece/Pieces

Intshayelelo Intshayelelo

I-LTI480HS01 Isisombululo sokubonisa siyi-1920 (i-RGB) × 1080 (FHD), umyinge we-16: 9 (ububanzi), kwaye iipikseli zilungelelaniswe kwi-RGB yemivimbo yeRGB. Ubungakanani bendawo yokubonisa buyi-1054.08 × 592.92 (W) MM, ubungakanani obubonakalayo yi-1079.82 (D) (H) (D ) I-MM, unyango lomhlaba nguMatte (haze 25%), i-haides enzima (2h)

Iqondo lokusebenza elisebenzayo lale modyuli yi-0 ° 8 ° C, kunye neqondo lokugcina londolozo ngu -0 ~ 65 ° C. Le modeli ilungele ukusetyenziswa kwemiqondiso yedijithali.

hight brightness lcd moudle

Q: Ngaba ikhona enye ubungakanani okanye ingcaciso enokukhetha?

A: Ukuba ufuna ubungakanani obahlukileyo okanye iinkcukacha, siya kubonelela ngesona senqwa efanelekileyo ngokweemfuno zakho.

Q: Lingakanani iwaranti?

A: Ngaphandle komonakalo obangelwe zizinto zabantu, iwaranti yonyaka omnye ukusuka kumhla wokuhanjiswa. Iimeko ezizodwa ziya kwaziswa.

Q: Lingakanani iwaranti?

A: Ngaphandle komonakalo obangelwe zizinto zabantu, iwaranti yonyaka omnye ukusuka kumhla wokuhanjiswa. Iimeko ezizodwa ziya kwaziswa.

high brightness LCD

brand	SAMSUNG	Model name	LTI480HN01
size	46 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1080	Pixel configuration	RGB vertical bar
Display Area	1054.08×592.92(H×V)mm	Surface treatment	Fog surface(Haze 25%)，Hard coating (2H)
Visual size	1060.08×598.92(H×V)mm	Contrast Ratio	4000:1 (Typ.) (TM)
Brightness(cd/m²)	700cd/m²(Typ.)or customized	Outline dimension	1079.88×618.72×22.4(H×V×D)mm
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	work environment	Storage temperature: -20 to 65 °C Operation Temperature: 0 to 50 °C
Signal interface	LVDS (2 ch, 8-bit) ,erminal,51pins
supply voltage	12.0V (Typ.)

Iithegi ezishushu: 46 "I-LCI480111 datasheet, i-Screen Screen, i-Incy Screen, i-Inche Screen Screen, i-WCHE SCRING , Iphaneli ye-LCD, imodyuli ye-LCD, ibonisa ukukhanya okuqaqambileyo.
