Min. Myalelo:1 Piece/Pieces
Ibhanti: Ukunyuka
Imveliso: 210k
Indawo yokuQala: China
Sekiso: CE/ROSH/ISO9001
I-LTI480H02 I-Modyule Screen, ixhotywe ngokukhanya okungekho mthethweni, kubandakanya ukuqhuba i-LED yokuqhuba, akukho phepha. Iqondo lokushisa elisebenzayo leli candelo 0 ° 8 ° C, kunye neqondo lokugcina londolozo ngu -0 ~ 65 ° C. Ilungele iimveliso ezinje ngemiqondiso yedijithali.
Isisombululo se-LTI480HITS02 (RGB) (RGB) × 1080 (FHD), umyinge we-16: 9 (ububanzi), kwaye iipikseli zilungisiwe kwimitya ye-RGB. Ubungakanani bendawo yokubonisa yesikrini sokubonisa yi-1054.08 (w) × 592.92 (H) × 22.9 (d) (W) I-598.92 (H) MM, unyango lomphezulu yi-Matte (haze 25%), i-haiting haider (2h), kunye nomthombo wokukhanya okukrakra (ezantsi) kuyasetyenziswa.
Q: Ngaba uyenza (umzi-mveliso)?
A: Ewe, sithi. Inkonzo ye-OEM / i-ODM iyafumaneka apha. Kuluyolo lwethu ukubonelela ngesisombululo esifanelekileyo kuwe.
Q: Singaqinisekisa njani umgangatho?
A: Soloko uhlolo lokugqibela ngaphambi kokuba uthunyelwe;
| brand | SAMSUNG | Model name | LTI480HN02 |
| size | 48 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 | Pixel configuration | RGB vertical bar |
| Display Area | 1054.08×592.92(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (2H) |
| Visual size | 1060.08×598.92(H×V)mm | Contrast Ratio | 4000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 1079.88×618.72×22.9(H×V×D)mm |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) | work environment | Storage temperature: -20 to 65 °C Operation Temperature: 0 to 50 °C |
| Signal interface | LVDS (2 ch, 8-bit) ,erminal,51pins |
|
|
| supply voltage | 12.0V (Typ.) |
|
|
Iithegi ezishushu: Samsung 48inch LTI480UVINGE , Iphaneli ye-LCD, imodyuli ye-LCD, ibonisa ukukhanya okuqaqambileyo.
